Sorry, this product is no longer offered for sale. For recommended replacements see residual-gas-analyzers.

Specifications

  • Mass Range
    1-145 amu in 85 ms
    1-300 amu in 120 ms
  • Data I/O
    USB 2.0, full speed, 12 Mb/sec
  • Trigger In (BNC)
    50 ohm, positive TTL edge trigger, 1 ms minimum
  • Trigger Out (BNC)
    50 ohm, active high, TTL, frame scan, or VQI status
  • Analog In (BNC)
    10K ohm, 0-10 V, 12 bit resolution
  • Analog Out (BNC)
    0 to +5 V with 30 KHz 3 db bandwidth, raw data scan output
  • Front Panel LEDs
    ExT TP, USB, Trigger IN, Trigger OUT, Analog IN, Analog OUT
  • Operating Temperature
    0° to 40°C (32°F to 104°F)
  • Storage Temperature
    0° to 80°C (32° to 176°F)
  • Relative Humidity
    <90%, non-condensing
  • Dimensions
    178.5 x 104.9 x 40.1 mm (7.03 x 4.13 x 1.58 inches)
  • Weight
    720 grams (25 ounces)
  • Compliance
    CE
  • Gas Display Table
    Automatic listing by amu or gas type (user selectable)
  • Input Power Plug
    DC power jack, 5.5 mm OD x 2.5 mm ID x 11 mm long
