GS Series 2450 MHz Industrial Microwave Generators
Model: GS10048
GS Series 2450 MHz Industrial Microwave Generators
Model: GS10048
Overview
Overview
The Alter® GS10048 Microwave Generator provides 10 kW at 2450 MHz with 3 x 480 V input, and is equipped with reflected power detection for demanding industrial applications.
Technical Specs
- Type2450 MHz Industrial Microwave Generator
- Maximum Power Output1-10 kW
- Frequency2450 MHz
- Power Regulation10-100%
- Line Load Regulation3%
- RippleMax ±5% of output power
- Ambient TemperatureUp to 40°C maximum
- Microwave ConnectionsWR340 waveguide with PDR26 flange
- Remote ControlOptions: PLC, RS232, ANYBUS
- IsolatorExternal
- Input Power3 x 480 VAC, 50/60 Hz
- ComplianceCE
