GS Series 2450 MHz Industrial Microwave Generators
Model: GS15048
GS Series 2450 MHz Industrial Microwave Generators
Model: GS15048
Overview
Overview
The Alter® GS15048 Microwave Generator provides 15 kW at 2450 MHz with 3 x 480 V input, and is equipped with reflected power detection for demanding industrial applications.
Technical Specs
- Type2450 MHz Industrial Microwave Generator
- Maximum Power Output1-15 kW
- Frequency2450 MHz
- Power Regulation10-100%
- Line Load Regulation3%
- RippleMax ±5% of output power
- Ambient TemperatureUp to 40°C maximum
- Microwave ConnectionsWR430 waveguide with PDR22 flange
- Remote ControlOptions: PLC, RS232, ANYBUS, Display
- IsolatorExternal
- Input Power3 x 480 VAC, 50/60 Hz
- ComplianceCE
